Telemecanique

ZCMD41L1 OsiSense 4-Pole Fixed Limit Switch Body With Positive Opening, 2NO-2NC Contact, For Use With XCMD Standard Format Limit Switch, 1.5 A at 240 V AC, 0.1 A at 250 V DC Contact

MFR:
Telemecanique Sensors
MFR #:
ZCMD41L1
UPC:
785901531753
Item #:
401742

Availability

Location Available Qty
Available Available to Order
$98.80 each

This ZCM body/contact assembly with connector has standard contacts and a Zamak body. It has 2 x NO + 2 x NC snap action contacts and is pre-cabled (1 meter cable). It can be matched with any head, actuator or connector from the XCKD, XCKP and XCKT ranges.

Manuals and Documentation
Catalog Number ZCMD41L1
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin Indonesia
Made in USA No
Action Snap action
Amperage Rating 6
Application XCMD
Connection Fixed cable
Contact Configuration 2 NC + 2 NO
Number of Poles 4
Operating Cycles 5000000 CYCLES, DC-13 24 V, 3 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 48 V, 2 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 120 V, 1 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C
Special Features FIXED
Standard IEC, UL LISTED, CSA
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=880350&lang=en-us
UPC 785901531753
GTIN 03389110299441
Item Type Limit switch body
Size 0.63
