5G108-BC5 8-Conductor 8-Position UTP Connector, Cat 5e Module, Panel Mount, 1 Ports, Plastic, Crimson Red
- MFR:
- Leviton
- MFR #:
- 5G108-BC5
- UPC:
- 078477203088
- Item #:
- 3695
5G108-BC5 8-Conductor 8-Position UTP Connector, Cat 5e Module, Panel Mount, 1 Ports, Plastic, Crimson Red
- MFR #:
- 5G108-BC5
- UPC:
- 078477203088
- Item #:
- 3695
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$203.54
each
Leviton® QuickPack® eXtreme® QuickPort® UTP Connector, 8-Conductor 8-Position, Cat 5e Module, Panel Mounting, 1 Ports, Plastic, Crimson Red, 0.89 in H x 0.64 in W x 1.17 in D Dimensions
Manuals and Documentation
Features
- Permanently laser engraved
- Fire retardant
- Individual port configurability allows specification flexibility
- Narrow body connector allows high port density in a small area
- Robust 1-piece lead frame design
- Performance supports high megabit and shared sheath application
- To ID ports, use different colored modules for each application
- Dual wiring code label allows connector to be wired to either T568A/T568B
- Phosphor bronze contact material
| Manufacturer Part Number | 5G108-BC5 |
| Brand | Leviton® |
| Manufacturer | Leviton |
| UPC | 078477203088 |
| Country Of Origin | US |
| Color | Crimson Red |
| Dimensions | 0.89 in H x 0.64 in W x 1.17 in D |
| Material | Plastic |
| Mounting Type | Panel |
| Type | 8-Conductor 8-Position |
| Alternative Part Number | 7363820 |
| Manufacturer Item Status | Active |
| Country | USA |
| Warranty | 1 Year Limited |
| Standards Approvals | ANSI/TIA-568-C.2/1096-A | cULus Listed | CSA Certified | IEEE 802.3at/802.3bt | NEC Article 800 | FCC Part 68 | ACA Certified | UL94 V-0 Flammability Rating |
| Application | Commercial, Residential, MDU and High Megabit Applications |
| Module Type | Cat 5e |
| Number Of Ports | 1 |
