8536SCO1V02 Type S Non-Reversing NEMA Magnetic Starter, 110 VAC at 50 Hz, 120 VAC at 60 Hz V Coil, 2 Poles, Open Enclosure
- MFR:
- Schneider Electric
- MFR #:
- 8536SCO1V02
- UPC:
- 785901080411
- Item #:
- 35048
8536SCO1V02 Type S Non-Reversing NEMA Magnetic Starter, 110 VAC at 50 Hz, 120 VAC at 60 Hz V Coil, 2 Poles, Open Enclosure
- MFR #:
- 8536SCO1V02
- UPC:
- 785901080411
- Item #:
- 35048
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
Type S NEMA motor starters are used for full voltage starting and stopping of AC squirrel cage motors. Type S motor starters have ratings up to 810 amperes. This 2 pole NEMA Size 1 non-reversing starter has a 27 ampere rating. This NEMA Size 1 motor starter has single phase ratings of 2 HP at 115 VAC and 3 HP at 230 VAC. This non-reversing NEMA motor starter has a melting alloy type overload relay that uses Type B thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 110/120 VAC 50/60 Hz operating coil wired for common control. This NEMA starter is an open device without an enclosure. This starter is 6.77 inches tall, 3.50 inches wide and 4.22 inches deep. A wide variety of accessories are available for Type S starters. Type S non-reversing NEMA motor starters are UL listed and CSA certified.
Manuals and Documentation
| Catalog Number | 8536SCO1V02 |
| Manufacturer | Schneider Electric |
| Brand | SQUARE D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | United States |
| Made in USA | Yes |
| UPC | 785901080411 |
| GTIN | 00785901080411 |
