XMLB300D2S11 OsiSense XM Adjustable Differential Electromechanical Pressure Switch, 300 bar Pressure, 200 bar Differential, 1CO Contact, Screw Clamp/Cable Gland Connection, 3 A at 120 V AC/1.5 A at 240 V AC/0.1 A at 250 V DC Contact
- MFR:
- Telemecanique Sensors
- MFR #:
- XMLB300D2S11
- UPC:
- 785901876977
- Item #:
- 330502
XMLB300D2S11 OsiSense XM Adjustable Differential Electromechanical Pressure Switch, 300 bar Pressure, 200 bar Differential, 1CO Contact, Screw Clamp/Cable Gland Connection, 3 A at 120 V AC/1.5 A at 240 V AC/0.1 A at 250 V DC Contact
- MFR #:
- XMLB300D2S11
- UPC:
- 785901876977
- Item #:
- 330502
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$931.43
each
This XMLB electromechanical pressure switch has an adjustable differential for regulation of 2 thresholds and a zinc alloy body with a range scale window. This pressure switch is designed for regulation of pressure between 2 thresholds for hydraulic oils at temperatures up to 160C. It is fixed directly on tubage. It provides zinc alloy enclosure for robust performance. 3 million cycles mechanical durability for minimum required maintenance on your pressurized fluid circuits. It complies with CCC, EN/IEC 60947-5-1, CSA C22.2 No.14, LROS, UL 508, EAC, BV. It is designed for very high pressures up to 300bar, this makes it ideal for hydraulic presses, water jet cutting machines.
Manuals and Documentation
| Catalog Number | XMLB300D2S11 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Unknown |
| Made in USA | No |
| Application | Regulation between 2 thresholds;-;Control circuit |
| Contact Configuration | 1 C/O |
| Enclosure | Zinc alloy |
| Operating Cycles | 60 CYC/MN |
| Process Connection | G 1/4 (FEMALE) ISO 228 |
| Special Features | IP66 CONFORMING TO EN/IEC 60529,SCREW-CLAMPS TERMINALS 1 X 0.5...2 X 2.5 MM²-1 CONNECTOR PG 13 |
| Standard | CSA C22.2 NO 14-EN/IEC 60947-5-1-CE-UL 508,CSA-BV-EAC-LROS (LLOYDS REGISTER OF SHIPPING)-CCC-UL,IP66 EN/IEC 60529,CLASS I IEC 1140-CLASS I IEC 536-CLASS I NF C 20-030 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=862494&lang=en-us |
| UPC | 785901876977 |
| GTIN | 03389110714388 |
| Item Type | Electromechanical pressure sensor;Electromechanical pressure sensor;Adjustable differential |
| Operating Temperature | -25-70 A Degrees C |
| System Pressure | 4351.13 |
