XMLA500D2S11 OsiSense XM Fixed Differential Electromechanical Pressure Switch, 500 bar Pressure, 1CO Contact, Screw Clamp/Cable Gland Connection, 3 A at 120 V AC/1.5 A at 240 V AC/0.1 A at 250 V DC Contact
- MFR:
- Telemecanique Sensors
- MFR #:
- XMLA500D2S11
- UPC:
- 785901769651
- Item #:
- 329232
XMLA500D2S11 OsiSense XM Fixed Differential Electromechanical Pressure Switch, 500 bar Pressure, 1CO Contact, Screw Clamp/Cable Gland Connection, 3 A at 120 V AC/1.5 A at 240 V AC/0.1 A at 250 V DC Contact
- MFR #:
- XMLA500D2S11
- UPC:
- 785901769651
- Item #:
- 329232
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$854.20
each
This XMLA electromechanical pressure switch has a fixed differential for detection of a single threshold and a zinc alloy body with a range scale window. This pressure switch is designed for detection of a single pressure threshold in hydraulic oils up to 160C. It is fixed directly on tubage. It provides zinc alloy enclosure for robust performance. 6 million cycles mechanical durability for minimum required maintenance on your pressurized fluid circuits. It complies with CCC, EN/IEC 60947-5-1, CSA C22.2 No.14, LROS, UL 508, EAC, BV. It is designed for very high pressures up to 500bar, this makes it ideal for hydraulic presses, water jet cutting machines.
Manuals and Documentation
| Catalog Number | XMLA500D2S11 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Indonesia |
| Made in USA | No |
| Application | Detection of 1 single threshold;-;Control circuit |
| Contact Configuration | 1 C/O |
| Enclosure | Zinc alloy |
| Operating Cycles | 60 CYC/MN |
| Process Connection | G 1/4 (FEMALE) ISO 228 |
| Special Features | IP66 CONFORMING TO EN/IEC 60529,SCREW-CLAMPS TERMINALS 1 X 0.5...2 X 2.5 MM²-1 CONNECTOR PG 13 |
| Standard | CE-EN/IEC 60947-5-1-CSA C22.2 NO 14-UL 508,IP66 EN/IEC 60529,UL-EAC-CSA-LROS (LLOYDS REGISTER OF SHIPPING)-BV-CCC,CLASS I IEC 1140-CLASS I IEC 536-CLASS I NF C 20-030 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=861858&lang=en-us |
| UPC | 785901769651 |
| GTIN | 03389110712391 |
| Item Type | Electromechanical pressure sensor;Electromechanical pressure sensor;Fixed differential |
| Operating Temperature | -25-70 A Degrees C |
| System Pressure | 7251.89 |
