SCHNEIDER ELECTRIC

LC2K1201G7 TeSys K LC2K Reversing Miniature IEC Contactor, 120 V AC V Coil, 12/16/20 A, 3NO Contact, 3 Poles

MFR:
Schneider Electric
MFR #:
LC2K1201G7
Item #:
313621

Availability

Location Available Qty
Available Available to Order
$237.97 each

LC2K1201G7 is a compact 3-pole TeSys K reversing contactor from Schneider Electric for motor applications. Rated 12A AC-3 5.5kW@400V, it includes a 120V 50/60Hz AC coil, 2NC auxiliary contacts, a mechanical interlock and pre-wired reversing circuit. LC2K1201G7 is a 3-pole TeSys K reversing contactor from Schneider Electric for simple motor applications rated up to 5.5kW@400V. Very compact, DIN-rail compatible, with connections by screw clamp terminals, it is assembled with a mechanical interlock and a pre-wired reversing circuit. It includes a 120V 50/60Hz AC coil and 2NC built-in auxiliary contacts. Available worldwide, it complies with multi-standards (IEC, UL, CSA, CCC, EAC, Marine). Very compact, 90mm wide, for DIN-rail and panel mounting. Assembled with mechanical interlock and pre-wired reversing circuit. Provides a 120V AC coil compatible 50/60Hz and 2NC built-in auxiliary contact. Can be completed with auxiliary contact blocks (LA1K, LA2K) and thermal relays (LR2K).

Manuals and Documentation
Catalog Number LC2K1201G7
Manufacturer Schneider Electric
Brand SCHNEIDER ELECTRIC
Warranty Description Contractual Warranty:18 months
Country of Origin France
Made in USA No
Application Resistive load;motor control
Coil Voltage 120 V AC 50/60 Hz
Contact Configuration 1 NC
Standard CB Scheme;CCC;UL;CSA;EAC;CE;UKCA
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=630002&lang=en-us
GTIN 03389118023505
Item Type Reversing contactor;LC2K
Cross Reference Products Rockwell VB7M101|Schneider LC2K1201G7|Siemens 3RA13178XB301AK6|Siemens 3RR0T1702AK6|Telemecan LC2K1201G7
