1PLD2/04 4-Port 2-Sided Entry Multi-Port Connector, Aluminum/Copper/Stranded Conductor, 14 AWG to 2/0 kcmil Run/Main, Aluminum
- MFR:
- Burndy, a Hubbell affiliate
- MFR #:
- 1PLD2/04
- UPC:
- 781810294871
- Item #:
- 28688
1PLD2/04 4-Port 2-Sided Entry Multi-Port Connector, Aluminum/Copper/Stranded Conductor, 14 AWG to 2/0 kcmil Run/Main, Aluminum
- MFR #:
- 1PLD2/04
- UPC:
- 781810294871
- Item #:
- 28688
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$137.59
each
Manuals and Documentation
| Catalog Number | 1PLD2/04 |
| Manufacturer | Burndy, a Hubbell affiliate |
| Brand | BURNDY |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | For Indoor Use Only, Copper Or Stranded Aluminum |
| Material | Aluminum |
| Special Features | Features: UV Rated Plastisol Covered AL6061-T6 Aluminum Body Saves Time By Eliminating The Need For Taping, Oxide Inhibitor Pre-Installed Inhibits Moisture And Contaminants From Entering The Contact Area, Range-Taking Capability Reduces The Number Of Connectors Carried In Inventory, UL486B Listed, AL9CU, 600 V 90 DEG C, UNITAP Rated For Code Conductor Only, Wire Entry: Double, Hex Size (key): 3/16 IN, Conductor Size (run - Range): 14 - 2/0 AWG, Number Of Ports: 4, Torque: 120 IN-LB, Type Of Insulation: UV Rated Plastisol |
| UPC | 781810294871 |
| GTIN | 00781810294871 |
| Item Type | BIBD, Multi-Port |
| Temperature Rating | 194 Degrees F |
