PSG120E24RM 1-Phase Switcher DC Power Supply, 100 to 240 V AC Input, 24 VDC Output, 120 W Power Rating, 2.2/5 A, DIN Rail Mount
- MFR:
- Eaton
- MFR #:
- PSG120E24RM
- UPC:
- 786685520988
- Item #:
- 284162
PSG120E24RM 1-Phase Switcher DC Power Supply, 100 to 240 V AC Input, 24 VDC Output, 120 W Power Rating, 2.2/5 A, DIN Rail Mount
- MFR #:
- PSG120E24RM
- UPC:
- 786685520988
- Item #:
- 284162
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$357.38
each
The PSG line of general purpose power supplies is used in a wide variety of industrial control applications. Applications include communication networks, sensors, PLCs and many other electrical systems. Each model is equipped with the options of a rugged metal or plastic housing, heavy-duty screw or finger-safe terminals and a variety of protection features. The PSG line offers the flexibility of operating with a universal input voltage of 100240 Vac. It also provides system protection and continuous operation during brief current surges of up to 150% of nominal current for components with high in-rush demands.
Manuals and Documentation
| Catalog Number | PSG120E24RM |
| Manufacturer | Eaton |
| Brand | Eaton |
| Country of Origin | Thailand |
| Made in USA | No |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs|Commercial / Institutional Buildings / Structures - Power Distribution and Controls |
| Material | Metal |
| Phase | 1 |
| Special Features | Varistor transient surge voltage, surge voltage protection against internal surge, safety class 1 with ground connection |
| Standard | cULus/UL 60950-1,EN Listed,UL 508,CSA Certified,IEC Rated,cUL Certified,RoHS Compliant,German Safety,CE Marked |
| UPC | 786685520988 |
| GTIN | 00786685520988 |
| Item Type | General purpose power supply |
| Wattage | 120W |
