Telemecanique

XUB9BPBWM12 OsiSense XU Simply Easy 3-Wire 90 deg Lateral Corrosion-Resistant Dusttight/Watertight Photoelectric Sensor, M18 Cylindrical Shape, 3 m, Infrared Sensing Beam, 1 ms Response, PNP 1NC Output

MFR:
Telemecanique Sensors
MFR #:
XUB9BPBWM12
UPC:
785901700234
Item #:
253492

Availability

Location Available Qty
Available Available to Order
$137.40 each

This product is part of the XU range, an offer of photoelectric sensors. This photoelectric sensor in XUB cylindrical M18 design. It has a polarised reflex detection system. It supports nominal sensing distance of 2m polarised reflex need reflector XUZC50 with 1 normally closed PNP discrete output signal. It is furnished with 4-pin M12 male connector for electrical connection. This photoelectric sensor with red polarised reflex emission and it has 2 LEDs for output state and stability. It is an IP65, IP67 and IP69K rated product. It is a photoelectric sensor with a rated supply voltage of 12V to 24V DC with reverse polarity protection, a no-load current consumption of =50mA and a switching frequency of =500Hz. The enclosure is made of nickel plated brass with PMMA lens. Its dimensions are 76mm (Length) x 45mm (Width) x 99mm (Height) and weighs 0.05kg. It is ideal for material handling, packaging, labelling, assembly, lift, escalators or food and beverage industries. This product is certified by CE, UL and CSA.

Manuals and Documentation
Catalog Number XUB9BPBWM12
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin France
Made in USA No
Application -
Connection 1 male connector M12, 4 pins
Enclosure IP65 DOUBLE INSULATION CONFORMING TO IEC 60529-IP67 DOUBLE INSULATION CONFORMING TO IEC 60529-IP69K DOUBLE INSULATION CONFORMING TO DIN 40050,NICKEL PLATED BRASS
Operating Cycles <= 500 Hz
Output PNP;1 NC;Discrete;Solid state
Sensing Range 2-2 M POLARISED REFLEX NEED REFLECTOR XUZC50,> 3.28...16.4 FT (> 1...5 M)
Special Features 1 LED yellow)output state;1 LED red)stability
Standard CE-UL-CSA,IP67 DOUBLE INSULATION IEC 60529-IP65 DOUBLE INSULATION IEC 60529-IP69K DOUBLE INSULATION DIN 40050
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=873168&lang=en-us
UPC 785901700234
GTIN 03389110159851
Item Type General purpose single mode;Polarised reflex;Cylindrical M18;Photo-electric sensor
Size 1.73
Environmental Conditions WATER TIGHT, DUST TIGHT AND CORROSION RESISTANT (INDOOR)
Operating Temperature -25-55 A Degrees C
Voltage Rating 12...24 V DC reverse polarity protection
