8502SGO2V06 Non-Reversing Type S Contactor, 440 V AC at 50 Hz to 480 V AC at 60 Hz V Coil, 3 Poles
- MFR:
- Schneider Electric
- MFR #:
- 8502SGO2V06
- UPC:
- 785901851110
- Item #:
- 250492
8502SGO2V06 Non-Reversing Type S Contactor, 440 V AC at 50 Hz to 480 V AC at 60 Hz V Coil, 3 Poles
- MFR #:
- 8502SGO2V06
- UPC:
- 785901851110
- Item #:
- 250492
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
Type S non-reversing magnetic contactors are used to switch heating loads, capacitors, transformers, and electric motors where overload protection is provided separately. Type S contactors have ratings up to 810 amperes. This 3 pole NEMA Size 5 non-reversing contactor has a 270 ampere rating. Three phase NEMA Size 5 contactors have 75 HP at 200, 100 HP at 230 VAC and 200 HP at 460 and 575 VAC ratings. This NEMA contactor has a 100 kA maximum SCCR rating per UL508A when protected by an appropriate circuit breaker or fuse. These contactors are available with replaceable coils in a wide variety of voltages. This contactor has a 440/480 VAC 50/60 Hz coil that is wired for common control. This NEMA contactor is an open device without an enclosure. This contactor is 12.31 inches tall, 8.67 inches wide and 8.75 inches deep. A wide variety of accessories are available for Type S contactors. Type S NEMA contactors are UL listed and CSA certified.
Manuals and Documentation
| Catalog Number | 8502SGO2V06 |
| Manufacturer | Schneider Electric |
| Brand | SQUARE D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | United States |
| Made in USA | Yes |
| UPC | 785901851110 |
| GTIN | 00785901851110 |
