The vibration resistant male tab disconnect is made of copper and is nickel-plated. It is fully insulated in a yellow, oversized nylon housing. It has a tab size of 0.250 x 0.032 (6.3 x 0.8 mm) and supports a wire range of 12-10 AWG (4.0-6.0 mm). It is 0.96 (24.4 mm) long and 0.22 (5.6 mm) wide. The disconnect has a standard barrel configuration and a butted seam barrel. It comes in bottles of 25.
Manuals and Documentation
- Catalog Number
- DNF10-250FIMB-Q
- Manufacturer
- Panduit
- Brand
- Panduit
- Country of Origin
- Mexico
- Made in USA
- No
- Color
- Yellow
- Connection
- Standard
- Finish
- Nickel-Plated
- Insulation
- Nylon
- Material
- Copper
- Standard
- UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
- UPC
- 074983119028
- GTIN
- 00074983119028
- Item Type
- Disconnect
- Temperature Rating
- 221 Degrees Fahrenheit (105 Degrees Celsius)
- Voltage Rating
- 600
- Wire Size
- #10 AWG
- Cross Reference Products
- 3M 73M-250-32-NBL|3M MNG10-250DMIX|ABBInstall 10RC-251T|ABBInstall 251T|ABBInstall RC25177|ABBInstall TNF10-250MD|ABBInstall TNF10250MDDXV|Burndy FQN10M25X03D|Burndy NQ10M250D|Grainger 5X429
