Discontinued
Mersen

STP4803PYGM Surge-Trap Pluggable Surge Protective Device, 277 V AC, 50/60 Hz, 3 Poles, 200 kA SCCR, 3 Phase

MFR:
Mersen
MFR #:
STP4803PYGM
UPC:
782001417321
Item #:
235952

Availability

Location Available Qty
Available Available to Order

Surge-Trap Pluggable SPD provides advanced overvoltage protection. Utilizing Mersen's patented TPMOV design, which does not require fuses, a fuse holder or additional wiring in meeting the UL 1449 Third Edition standards thus providing substantial cost savings and reduced installation times. It also features a visual indicator, easy installation, fail-safe design, mechanical coding and remote monitoring. The Surge-Trap Pluggable SPD base is designed to be mounted on 35mm DIN-rail while plugs are easily replaceable upon failure without touching the base or the hassle of rewiring. 277/480 Volts 3P Wye system type without N-G mode .

Manuals and Documentation
Catalog Number STP4803PYGM
Manufacturer Mersen
Brand Mersen
Country of Origin Mexico
Made in USA No
Application AC/DC distribution Power supplies Industrial automation Telecommunications Motor controls and starter systems Programmable logic controller (PLC) applications Power transfer equipment HVAC applications AC drives UPS systems Security systems IT / Data centers Medical equipment
Connection Box
Mounting Din Rail
Short Circuit Rating 200 KA
Special Features Easy installation or retrofit DIN-rail mountable Fail-safe /self-protected design Remote indicator (optional) Visual indicator IP20 finger-safe design 2 year warranty No additional overcurrent protection devices needed Easy to replace modules
Standard UL 1449 Third Edition Approved, File No E210793 Type 1 Component Assembly IEC 61643-1 RoHS compliant ANSI/IEEE C62.41 CE
UPC 782001417321
GTIN 00782001417321
Item Type Surge-Trap® SPD
Type of Indicators Microswitch
Voltage Rating 277
