695WG Grounding Three-Way Combination Switch and Pilot Light, White
- MFR:
- Legrand-Pass & Seymour
- MFR #:
- 695WG
- UPC:
- 785007006193
- Item #:
- 223872
695WG Grounding Three-Way Combination Switch and Pilot Light, White
- MFR #:
- 695WG
- UPC:
- 785007006193
- Item #:
- 223872
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$58.6699
each
3-way, Single Pilot Light, Combination Switch, 15A, 120/125As, White.
| Catalog Number | 695WG |
| Manufacturer | Legrand-Pass & Seymour |
| Brand | Legrand-Pass & Seymour |
| Country of Origin | Mexico |
| Made in USA | No |
| Action | 3W & Pilot Light |
| Actuator | Toggle |
| Amperage Rating | 15 |
| Application | Residential/Commercial |
| Connection | Side wire |
| Contact Configuration | N-O |
| Contact Rating | 15 Amp, 120/125 VAC |
| Mounting | Wall |
| Number of Poles | 3 |
| Operating Cycles | 30000 |
| Special Features | Easily accessible break-off for separate or common feed. Long-life red neon lamp in pilot light rated 1/25 Watt, 125V. Side wire #12 and #14 AWG. Two devices fit into the space of one. Grounding combination devices meet NEC Requirements. |
| Standard | UL20 |
| UPC | 785007006193 |
| GTIN | 00785007006193 |
| Item Type | Combination Three-Way Switch & Pilot Light |
| Size | 1.32 L x 0.94 W x 4.06 H |
| Environmental Conditions | Flammability: UL94 V2 |
| Operating Temperature | Maximum continuous +60 Degrees C, minimum -30 Degrees C |
| Voltage Rating | 120/125 |
