Q003ERCF Universal Commercial Encapsulated Buck Boost Transformer, 120/240 V AC Primary, 12/24 VAC Secondary, 3 kVA Power Rating, 50/60 Hz, 1 Phase
- MFR:
- Hammond Power Solutions
- MFR #:
- Q003ERCF
- UPC:
- 803423033958
- Item #:
- 213972
Q003ERCF Universal Commercial Encapsulated Buck Boost Transformer, 120/240 V AC Primary, 12/24 VAC Secondary, 3 kVA Power Rating, 50/60 Hz, 1 Phase
- MFR #:
- Q003ERCF
- UPC:
- 803423033958
- Item #:
- 213972
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$1,331.49
each
Manuals and Documentation
| Catalog Number | Q003ERCF |
| Manufacturer | Hammond Power Solutions |
| Brand | HPS |
| Country of Origin | Canada |
| Made in USA | No |
| Application | General purpose for raising supply voltage caused by line drop or equipment demand on the distribution system, or lower voltage caused by increased system voltages due to supply line adjustments |
| Enclosure | NQ5-N3R - Indoor or Outdoor |
| Frequency Rating | 50/60 HZ |
| Mounting | Wall |
| Special Features | Encapsulated transformers can be used to buck and boost voltage in single and three phase applications where supply voltages are frequently above or below nominal. These transformers can also be used in low voltage transformer application. |
| Standard | CSA, UL, Class 1 Div II |
| UPC | 803423033958 |
| GTIN | 00803423033958 |
| Item Type | Transformer > Dry Type > Buck-Boost |
| Length | 7.75 |
| Length UOM | Inch |
| Width | 10.0 |
| Width UOM | Inch |
| Height | 17.25 |
| Height UOM | Inch |
| Temperature Rating | Typical 30 Average/ 40 Maximum DEG C |
