Discontinued
Square D

9007C54A2Y1901 Heavy Duty Plug-In Limit Switch, 600 V, 6 A, Lever Actuator, 1CO 1 Form Z SPDT-DB Contact, 1 Poles

MFR:
Schneider Electric
MFR #:
9007C54A2Y1901
UPC:
785901045731
Item #:
207578

Availability

Location Available Qty
Available Available to Order

LIMIT SWITCH 600V 10AMP C +OPTIONS

Manuals and Documentation
Catalog Number 9007C54A2Y1901
Manufacturer Schneider Electric
Brand Square D
Country of Origin Mexico
Made in USA No
Action FROM LEFT AND RIGHT-CW AND CCW,LATERAL APPROACH, 1 OR 2 PROGRAMMABLE DIRECTION,SNAP ACTION
Actuator ZINC SPRING RETURN WITHOUT OPERATING LEVER LOW DIFFERENTIAL)9007C LEVER
Amperage Rating 6
Application STANDARD BOX
Connection MALE CONNECTOR 7/8IN - 16 UN - 2 A MINI CONNECTOR, 5 PINS
Contact Configuration NC-NO
Contact Rating NEMA A600/Q600
Enclosure NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 6 NEMA TYPE 250-NEMA 6P NEMA TYPE 250-NEMA 12 NEMA TYPE 250-NEMA 13 NEMA TYPE 250
Mounting By The Body
Operating Cycles 1000000 CYCLES
Special Features WITHOUT
Standard 25 GN 10-150 HZ)IEC 60068-2-6,60 GN 9 MS IEC 60068-2-27,IP67 IEC 60529,CLASS 0 IEC 61140
UPC 785901045731
GTIN 00785901045731
Item Type LIMIT SWITCH,ROTARY HEAD
Size 1.55 IN,2.5 IN,4.02-4.02 IN
Environmental Conditions STANDARD ENVIRONMENT
Operating Temperature -20-185 A Degrees F STANDARD ENVIRONMENT
Voltage Rating 0.55 A 120 V DC-0.27 A 240 V DC-3 A 240 V AC NEMA-6 A 120 V AC NEMA
