NSYCVF300M115PF ClimaSys Self-Extinguishing Forced Ventilation Fan, 115 V AC, 0.32/0.35 A, 36 W Power Rating, 300 cu-m/hr Air Flow, IP54 Enclosure
- MFR:
- Schneider Electric
- MFR #:
- NSYCVF300M115PF
- Item #:
- 206282
NSYCVF300M115PF ClimaSys Self-Extinguishing Forced Ventilation Fan, 115 V AC, 0.32/0.35 A, 36 W Power Rating, 300 cu-m/hr Air Flow, IP54 Enclosure
- MFR #:
- NSYCVF300M115PF
- Item #:
- 206282
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$280.02
each
ClimaSys CV Axial motor ventilator. 115V 50Hz or 60Hz. 36 W 50 Hz, 36 W 60 Hz. Free flow rate with standard filter of 300 m3/h at 50 Hz and 300 m3/h at 60 Hz. 268 x 248 x 104 mm. Cut-out dimensions of 223 x 223 mm. Outlet grille injected thermoplastic (ASA PC), Grey RAL 7035. Connections terminals by faston connector. 2 protective grille on the front and rear surfaces. Protection IP54.
Manuals and Documentation
| Catalog Number | NSYCVF300M115PF |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | France |
| Made in USA | No |
| Consist of | 1 axial motor;2 protective grille on the front and rear surfaces;1 filter front of axial motor;1 outlet grille front;1 cut-out template;1 power cord |
| Input Voltage | 115 V 50/60 Hz |
| Material | Outlet grille injected thermoplastic (ASA PC) |
| Special Features | Faston connector |
| Standard | IP54 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=10178372&lang=en-us |
| GTIN | 03606480151293 |
| Item Type | Fan |
| Width | External: 248 mm |
| Height | External: 268 mm |
| Depth | External : 116 mm |
