SM952A124000 Hyde Park DeviceNet Cylindrical Adjustable Dual-Level Proximity Sensor, Ultrasonic, NPN Output, 1NO Contact, 12 to 24 V DC
- MFR:
- Telemecanique Sensors
- MFR #:
- SM952A124000
- Item #:
- 205627
SM952A124000 Hyde Park DeviceNet Cylindrical Adjustable Dual-Level Proximity Sensor, Ultrasonic, NPN Output, 1NO Contact, 12 to 24 V DC
- MFR #:
- SM952A124000
- Item #:
- 205627
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
This product is part of the Hyde Park range, an offer of ultrasonic sensors. This ultrasonic sensor in a cylindrical M30 design and adjustable sensing type window. It supports 1m nominal sensing distance and 1 NO NPN discrete output. It is an ultrasonic sensor with a rated supply voltage of 12V to 24V DC with overload, short circuit protection and current consumption of 100mA. It is furnished with 4-pin M12 male connector for electrical connection. It is an IP67 and NEMA 4X rated product. The enclosure is made of ULTEM with silicone rubber front. The sensor dimensions are 96mm (length) x 34.7mm (width) x 30mm (height). It weighs 0.26kg. The sensor is an M30 thread barrel sensor of ULTEM plastic with an M12 4-pin male connector. It is suitable for packaging, automotive, food and beverage processing applications. This product is certified by CE and UL. The Hyde Park ultrasonic sensors operate in diffuse, reflex and thru beam modes. This range of sensors even includes long distance detection models. Hyde Park ultrasonic sensors perform contactless, reliable and high performance detection regardless of the target's shape, texture, color or transparency.
Manuals and Documentation
| Catalog Number | SM952A124000 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Dual-level - setpoint |
| Connector | Male connector M12 4 pins |
| Enclosure | ULTEM |
| Material | Plastic |
| Sensing Range | 0.17�3.28�ft (0.0508�1�m) |
| Sensor | 30 MM,96 MM,ULTRASONIC SENSOR |
| Special Features | PLASTIC |
| Standard | 1 KV LEVEL 3 IEC 61000-4-4,10 V/M LEVEL 3 IEC 61000-4-3,30 GN IN ALL 3 AXES 11 MS IEC 60068-2-27,CE,IP67,UL |
| Supply Voltage | 12...24 V DC overload and short-circuit protection |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=61716977&lang=en-us |
| GTIN | 03389119118989 |
| Item Type | Ultrasonic sensor;Cylindrical M30 |
| Operating Temperature | 0-50 A Degrees C |
| Target Size | CYLINDER DIAMETER 1.6 MM - UP TO 305 MM SENSING DISTANCE |
