Discontinued
Schneider Electric

SM650A20244TE Hyde Park Cylindrical Fixed Miniature Proximity Sensor, Ultrasonic, NPN/PNP Output, 1NO Contact, 12 to 24 V DC

MFR:
Schneider Electric
MFR #:
SM650A20244TE
Item #:
198132

Availability

Location Available Qty
Available Available to Order

Ultrasonic sensor - discrete - 18 mm barrel - 12-24 V DC

Catalog Number SM650A20244TE
Manufacturer Schneider Electric
Brand Schneider Electric
Country of Origin United States
Made in USA Yes
Application DISCRETE PROXIMITY
Connection 4-Pin M18 x 1 ISO Thread, 1 Male M12
Connector 1 MALE CONNECTOR M12 4 PINS
Enclosure NEMA 4X INDOOR USE ONLY),ULTEM
Frequency Response 500 Hz
Material ULTEM
Output 4-Wire, PNP/NPN Discrete, (1) NO Function
Sensing Distance 47.6 mm - 50.8 m
Sensing Range 47.6-50.8 MM,50.8 MM
Sensor 18 MM,73.91 MM,ULTRASONIC SENSOR
Shape Cylindrical
Special Features PLASTIC
Standard 1 KV LEVEL 3 IEC 61000-4-4,10 V/M LEVEL 3 IEC 61000-4-3,30 GN IN ALL 3 AXES 11 MS IEC 60068-2-27,CE,IP67,UL
Supply Voltage 12...24 V DC OVERLOAD AND SHORT-CIRCUIT PROTECTION
GTIN 03389119102704
Item Type CYLINDRICAL M18,ULTRASONIC SENSOR
Size 73.91 mm Length x 18 mm Width x 18 mm Depth x 18 mm Height
Operating Temperature 0-60 A Degrees C
Target Size CYLINDER DIAMETER 1.59 MM - UP TO 63.5 MM SENSING DISTANCE
Voltage Rating 12 - 24 Volt
