GRLB150 Unilets LB-Style Dust-Ignitionproof Explosionproof Conduit Outlet Box With Cover, 1-1/2 in, 4.88 in Cover Opening, 72 cu-in, Triple Coated
- MFR:
- Emerson Electric
- MFR #:
- GRLB150
- UPC:
- 781381443852
- Item #:
- 190782
GRLB150 Unilets LB-Style Dust-Ignitionproof Explosionproof Conduit Outlet Box With Cover, 1-1/2 in, 4.88 in Cover Opening, 72 cu-in, Triple Coated
- MFR #:
- GRLB150
- UPC:
- 781381443852
- Item #:
- 190782
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$581.76
each
Appleton® explosionproof and dust-ignitionproof GR and GRF conduit outlet boxes are furnished with internal ground screw and O-ring. They are ideal for use in indoor and outdoor classified locations. These corrosion-resistant outlet boxes provide access for maintece, allow the connection of different lengths of conduit, and for changing the direction of conduit.
Manuals and Documentation
Features
- Offers ten hub arrangements
- Malleable iron bodies have high tensile strength and ductility and provide great resistance to corrosion, impact and shock
- Accurately tapped, tapered hub threads for tight, rigid joints and ground continuity
- General purpose wiring
- Function as sealing fittings when used with sealing covers
- Internally threaded body with externally threaded cover
- Covers have pry notches for bar or wrench
- Accommodate sealing, dome, hub and union hub covers and canopies
- Standard O-rings provide raintight fit
- Internal ground screw standard
- Smooth, rounded integral bushing in each hub type box protects conductor insulation
- Complies with a wide range of classified area requirements
- Corrosion resistant
- For pulling of wires
- Connect conduit lengths and change direction of conduit runs
- Provide access for maintece
- Chromate/epoxy powder coated/zinc electroplated finish
| Manufacturer Part Number | GRLB150 |
| Brand | Appleton® |
| Manufacturer | Emerson Electric |
| UPC | 781381443852 |
| Country Of Origin | MX |
| Capacity | 72 cu-in |
| Dimensions | 5.75 in H x 5.75 in W x 4.06 in D |
| Finish | Triple Coated |
| Material | Malleable Iron |
| Series | GR Series |
| Suitable For Use With | Threaded Metallic Conduit System |
| Type | LB-Style Dust-Ignitionproof Explosionproof |
| Size | 1-1/2 in |
| Alternative Part Number | 8345644 |
| Manufacturer Item Status | Active |
| Country | USA/Canada |
| Warranty | Limited |
| Standards Approvals | Class 1, Zone 1 And 2 IIA And IIB, UL File Number E10444, CSA C22.2 No. 25, C22.2 No. 30, CSA 013017 Certified, Class I, Division 1 And 2, Groups B, C, D Class II, Division 1 And 2, Groups E, F, G Class III |
| Application | Indoor/Outdoor Applications |
| Includes | Internal Ground Screw and O-Ring |
| Cover Opening Size | 4.88 in |
