QO1205264 Type QO Standard Miniature Circuit Breaker, 120/240 VAC, 48 VDC, 20 A, 5/10 kA Interrupt, 1 Poles, Thermal Magnetic Trip

MFR:
Schneider Electric
MFR #:
QO1205264
UPC:
785901311249
Item #:
180873

Availability

Location Available Qty
Available Available to Order
$42.18 each

QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 1 pole QO circuit breaker is rated at 20A at 120/240VAC. This unit provides 10kA breaking capacity and plug in mounting. This product has a high magnetic feature and comes in a quantity of 10. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.

Manuals and Documentation
Catalog Number QO1205264
Manufacturer Schneider Electric
Brand Square D
Warranty Description Contractual Warranty:18 months
Country of Origin United States
Made in USA Yes
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=398421&lang=en-us
UPC 785901311249
GTIN 00785901311249
