Bussmann

SC-3 Current Limiting Fast Acting Time Delay General Purpose Fuse, 3 A, 600 V AC/170 V DC, 10/100 kA Interrupt, G Class, Cartridge Body

MFR:
Eaton
MFR #:
SC-3
UPC:
051712250030
Item #:
178148

Availability

Location Available Qty
Available 54 ea
$89.92 each

Bussmann's SC type fuses are UL Class G and provide fast-acting (1/2-6 A) and time-delay (7-60 A) characteristics for circuit protection need. SC fuses are size rejecting in terms of their overall length thereby aiding in the prevention of overfusing

Manuals and Documentation

Features

  • Most economical overcurrent protection solution compared to circuit breakers
  • For use in various non-demanding, general purpose applications
  • Compact branch circuit units with high interrupt rating and current limitation
  • Size rejection by length helps prevent over fusing
  • Fuses 7 A and above have a degree of overload time delay that permits them to pass temporary overloads
  • 100 kA at 600 VAC, 10 kA at 170 VDC interrupt rating
Manufacturer Part Number SC-3
Brand Bussmann
Manufacturer Eaton
UPC 051712250030
Amperage Rating 3 A
Mounting Type Holder
Series SC Series
Type Current Limiting Fast Acting Time Delay
Voltage Rating 600 V AC/170 V DC
Alternative Part Number 7608224
Manufacturer Item Status Active
Country USA
Standards Approvals UL 248-5 Guide No. JDDZ File No. E4273 | CSA C22.2 No. 248.5, Class 1422-01 File No. 53787 | CE Certified
Application Fusible Branch Panelboards and HVAC Branch Circuit Protection Applications
Body Size 0.41 in Dia x 1.31 in L
Body Type Cartridge
Class G
Indicating Non Indicating Non-Indicating
Interrupt Rating 10/100 kA
Rejection Non Rejection Rejection
Response Time 12 s
Terminal Type Ferrule
