Discontinued
Schneider Electric

ASI67FFP22D Advantys Telefast Direct Connection Interface, For Use With AS-Interface Cabling System

MFR:
Schneider Electric
MFR #:
ASI67FFP22D
UPC:
785901446538
Item #:
177005

Availability

Location Available Qty
Available Available to Order

AS-Interface - direct IDC connection - V2.1 - standard - 2 I - 2 O - IP67

Catalog Number ASI67FFP22D
Manufacturer Schneider Electric
Brand Schneider Electric
Country of Origin Indonesia
Made in USA No
Application AS-INTERFACE CABLING SYSTEM
Connection 2 FEMALE CONNECTORS M12 STANDARD ACTUATOR-2 FEMALE CONNECTORS M12 STANDARD SENSOR-1 IDC AS-INTERFACE LINE-1 IDC AUXILIARY SUPPLY-1 JACK CONNECTOR
Enclosure COMPACT,PBT 30 GF VALOX 553
Mounting Screw
Special Features AS-INTERFACE POWER ON (ASI PWR) 1 LED GREEN)-AUXILIARY SUPPLY ON (AUX PWR) 1 LED GREEN)-FAULT 1 LED RED)-INPUT/OUTPUT STATUS 4 LEDS YELLOW),OFF IN THE ABSENCE OF COMMUNICATION
Standard +/-1 MM 2-13.2 HZ)GL-+/-1 MM 2-36 HZ)EN/IEC 60068-2-6-0.7 GN 13.2-100 HZ)GL-5 GN 36-150 HZ)EN/IEC 60068-2-6,10 V/M EN/IEC 61000-4-3 LEVEL 3,2 KV EN/IEC 60100-4-4 LEVEL 3,3 V EN/IEC 61000-4-6,30 GN 11 MS IEC 60068-2-27,750 A Degrees C 30 S EN/IEC 60695-2-11,8 KV EN/IEC 61000-4-2 LEVEL 3,AS-INTERFACE NO 55101-UL-CSA,IP54 IEC 60529 FOR USE AS TAP-OFF OR AT LINE END)-IP67 IEC 60529
UPC 785901446538
GTIN 00785901446538
Item Type DIRECT CONNECTION INTERFACE
Operating Temperature -25-70 A Degrees C EN/IEC 60529
Voltage Rating 21.6...27.2 V,26.5...31.6 V AS-INTERFACE LINE
