Hubbell Wiring Device - Kellems

SNAP1221INA 2-Position Commercial/Industrial Grade General Purpose Heavy Duty Standard Toggle Switch, 120 to 277 V AC, 20 A, 5540 W Power Rating, 2-Position Contact

MFR:
Hubbell Wiring Device-Kellems
MFR #:
SNAP1221INA
UPC:
783585186658
Item #:
171711

Availability

Location Available Qty
Available 10
$14.40 each

SNAPConnect Devices offer superior installation efficiency for new construction and renovations, while delivering safe, reliable connections. Instead of conventional wiring methods, SNAPConnects modular connector is installed during rough-in in lieu of pigtails. Once the walls are up, the protective covering is removed, and the terminal is simply snapped into the SNAPConnect device for a consistent connection every time. Once installed, SNAPConnects modular design enables simple device change-out by maintenance personnel.

Manuals and Documentation
Catalog Number SNAP1221INA
Manufacturer Hubbell Wiring Device-Kellems
Brand Hubbell Wiring Device - Kellems
Country of Origin United States
Made in USA Yes
Action Positive Snap
Actuator Toggle
Amperage Rating 20
Application SNAPConnect Heavy Duty
Color Ivory
Connection Connectorized
Contact Configuration Two Position
Contact Rating Per UL 20
Material Thermoplastic
Mounting Screw
Number of Poles 1
Operating Cycles 50,000 Cycles
Special Features SNAP Connect, Automatic self-grounding
Standard UL Listed
UPC 783585186658
GTIN 00783585186658
Item Type Toggle
Size 4.18 in x 1.3 in x 1.74 in
Environmental Conditions Indoor Dry unless protected by additional means
Operating Temperature Maximum continuous 75 Degrees C and minimum -40 Degrees C without Impact
Voltage Rating 120-277
Wattage 5540 W
