8536SCO3V07 Type S Magnetic Starter, 550 VAC at 50 Hz/600 VAC at 60 Hz V Coil, 3 Poles, Open Enclosure
- MFR:
- Schneider Electric
- MFR #:
- 8536SCO3V07
- UPC:
- 785901872207
- Item #:
- 170921
8536SCO3V07 Type S Magnetic Starter, 550 VAC at 50 Hz/600 VAC at 60 Hz V Coil, 3 Poles, Open Enclosure
- MFR #:
- 8536SCO3V07
- UPC:
- 785901872207
- Item #:
- 170921
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
Type S NEMA motor starters are used for full voltage starting and stopping of AC squirrel cage motors. Type S motor starters have ratings up to 810 amperes. This 3 pole NEMA Size 1 non-reversing starter has a 27 ampere rating. This NEMA Size 1 motor starter has 3 phase ratings of 7.5 HP at 200 and 230 VAC and 10 HP at 460 and 575 VAC. This non-reversing NEMA motor starter has a melting alloy type overload relay that uses Type B thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 550/600 VAC 50/60 Hz operating coil wired for common control. This NEMA starter is an open device without an enclosure. This starter is 6.77 inches tall, 3.50 inches wide and 4.22 inches deep. A wide variety of accessories are available for Type S starters. Type S non-reversing NEMA motor starters are UL listed and CSA certified.
Manuals and Documentation
| Catalog Number | 8536SCO3V07 |
| Manufacturer | Schneider Electric |
| Brand | SQUARE D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| UPC | 785901872207 |
| GTIN | 00785901872207 |
