DPF18-206FIB-3K Reel Smart Type DPF-FIB Reel Vibration-Resistant Female Disconnect, 18 AWG Conductor, 0.187 to 0.205 in W x 0.02 in THK Tab, Butted Seam/Funnel Entry Barrel, Brass, Red, Fully Insulated
- MFR:
- Panduit
- MFR #:
- DPF18-206FIB-3K
- UPC:
- 074983823710
- Item #:
- 169135
DPF18-206FIB-3K Reel Smart Type DPF-FIB Reel Vibration-Resistant Female Disconnect, 18 AWG Conductor, 0.187 to 0.205 in W x 0.02 in THK Tab, Butted Seam/Funnel Entry Barrel, Brass, Red, Fully Insulated
- MFR #:
- DPF18-206FIB-3K
- UPC:
- 074983823710
- Item #:
- 169135
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$0.461
each
The vibration resistant female disconnect is made of brass and is tin-plated. It is fully insulated in red premium nylon housing. It has a tab size of 0.187/0.205 x 0.02 (4.8/5.2 x 0.5 mm) and supports a wire range of 22-18 AWG (0.5-1.0 mm). It is 0.78 (19.8 mm) long and 0.31 (7.9 mm) wide. The disconnect has a funnel entry barrel configuration and a butted seam barrel. It comes in reels of 3000.
Manuals and Documentation
| Catalog Number | DPF18-206FIB-3K |
| Manufacturer | Panduit |
| Brand | Panduit |
| Country of Origin | Mexico |
| Made in USA | No |
| Color | Red |
| Connection | Funnel Entry |
| Finish | Tin-Plated |
| Insulation | Premium Nylon |
| Material | Brass |
| Standard | UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153 |
| UPC | 074983823710 |
| GTIN | 00074983823710 |
| Item Type | Disconnect |
| Temperature Rating | 221 Degrees Fahrenheit (105 Degrees Celsius) |
| Voltage Rating | 600 |
| Wire Size | #18 AWG |
