PV-10A10F High Speed Photovoltaic Fuse, 10 A, 1 kV DC, 50 kA Interrupt, Class: gPV, Cylindrical Body
- MFR:
- Eaton
- MFR #:
- PV-10A10F
- UPC:
- 051712204019
- Item #:
- 164793
PV-10A10F High Speed Photovoltaic Fuse, 10 A, 1 kV DC, 50 kA Interrupt, Class: gPV, Cylindrical Body
- MFR #:
- PV-10A10F
- UPC:
- 051712204019
- Item #:
- 164793
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$93.62
each
Eaton's Bussmann series photovoltaic gPV solar fuses are specifically designed to protect DC system up to 1500 V d.c. They are suitable for the DC protection of solar panels, combiner boxes, recombiner units and battery storage.
Manuals and Documentation
Features
- Meets UL and IEC photovoltaic standards for global acceptance
- Low wattage loss performance for energy efficiency
- Low temperature rise performance for more precise sizing
| Manufacturer Part Number | PV-10A10F |
| Brand | Bussmann |
| Manufacturer | Eaton |
| UPC | 051712204019 |
| EAN | 5027590505352 |
| Amperage Rating | 10 A |
| Material | Ceramic |
| Mounting Type | Holder |
| Series | PV Series |
| Voltage Rating | 1 kV DC |
| Alternative Part Number | 9933192 |
| Manufacturer Item Status | Active |
| Country | USA |
| Standards Approvals | CSA Certified ,IEC Rated ,UL approval pending ,UL Listed ,UL 2579 ,CCC Marked ,UL approval pending ,CCC Marked ,CSA Certified ,UL Listed ,IEC-Einstufung ,UL 2579,RoHS Compliant,CE Marked,CE-Kennzeichnung,RoHS-konform |
| Application | Solar Panel Combiner Boxes, Inverters, PV Wire Harnesses, Renewable Energy Generation, Alternative Energy Generation, Solar Renewable Energy Generation and Storage Systems Renewable Energy Applications |
| Body Size | 10 mm Dia x 38 mm L |
| Body Type | Cylindrical |
| Class | gPV |
| Element | Single |
| Indicating Non Indicating | Non-Indicating |
| Interrupt Rating | 50 kA |
| Rejection Non Rejection | Non-Rejection |
| Response Time | 1 to 3 ms |
| Terminal Type | Ferrule End |
