Telemecanique

ZCKM7H29 OsiSense XC Fixed Limit Switch Body, 2NC Contact, For Use With XCKM, ZCKM and ZCKM Series Standard Format Compact Limit Switch, 3 A at 240 V AC/0.27 A at 250 V AC Contact, IP66 Enclosure

MFR:
Telemecanique Sensors
MFR #:
ZCKM7H29
UPC:
785901682400
Item #:
160018

Availability

Location Available Qty
Available Available to Order
$163.20 each

This body, with a 2-pole contact block, is a separate part for the XCKM limit switches. Contacts: 1 NO + 1 NC, simultaneous, slow break. It is a classic format body, with 3 tapped entries for ISO M20 x 1.5 cable gland.

Manuals and Documentation
Catalog Number ZCKM7H29
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin Unknown
Made in USA No
Action Slow-break, simultaneous
Amperage Rating 10
Application XCKM
Connection Screw-clamp terminals 1 x 0.5...2 x 2.5 mm²
Contact Configuration 2 NC
Enclosure IP66
Number of Poles 2
Operating Cycles 5000000 CYCLES, DC-13 120 V, 1 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 24 V, 3 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 48 V, 2 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C
Special Features FIXED
Standard IK05,IP66
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=879926&lang=en-us
UPC 785901682400
GTIN 03389110514759
Item Type Limit switch body
Size 1.18
Environmental Conditions STANDARD ENVIRONMENT
Operating Temperature -25-70 A Degrees C STANDARD ENVIRONMENT
Voltage Rating 3 A 240 V, AC-15, A300 EN/IEC 60947-5-1 APPENDIX A-0.27 A 250 V, DC-13, Q300 EN/IEC 60947-5-1 APPENDIX A
