V1S-G-5M-PVC Cable Connector, 300 V AC, M12 Plug to Pigtail End Connection, 2 m L, TPU
- MFR:
- Pepperl+Fuchs
- MFR #:
- V1S-G-5M-PVC
- Item #:
- 1592397
V1S-G-5M-PVC Cable Connector, 300 V AC, M12 Plug to Pigtail End Connection, 2 m L, TPU
- MFR #:
- V1S-G-5M-PVC
- Item #:
- 1592397
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$48.78
each
Pepperl+Fuchs® Cable Connector, Series: V1S, 300 V AC, 0.166 A, M12 Plug to Pigtail End Connection, 2 m Length, 5 mOhm Resistance, -40 to 194 deg F, TPU, Gray
Manuals and Documentation
Features
- Knurled nut, suitable for tool assembly
- Immunity to vibration, with mechanical latching
- Gold plated contacts
- IP67/IP68/IP69K degree of protection
- Suitable for 2, 3 and 4-wire technology
- 4-pin
- 3 deg of pollution
- Spring-loaded contact socket contact elements
- 1 mm Dia pin
- Fine-strand wire, flexible cable
- 4.8 mm Dia cable sheath
- 4 x 0.34 sq-mm cable core cross-section
- 19 x 0.15 mm Dia conductor construction
- >10 x cable diameter bending radius, moving
- UL 94 V-2 flammability rating contact carrier, housing
- CuSn/Au contacts, Au contact surface, PVC cable, die cast zinc sleeve connector, PVC core insulation
| Manufacturer Part Number | V1S-G-5M-PVC |
| Brand | Pepperl+Fuchs® |
| Manufacturer | Pepperl+Fuchs |
| Amperage Rating | 0.166 A |
| Color | Gray |
| Length | 2 m |
| Material | TPU |
| Series | V1S |
| Temperature Rating | -40 to 194 deg F |
| Voltage Rating | 300 V AC |
| Manufacturer Item Status | Active |
| Country | USA |
| Standards Approvals | UL 94 V-2 |
| End Connection Type | M12 Plug to Pigtail |
| Resistance | 5 mOhm |
