PLA34080U33A PowerPact Molded Case Circuit Breaker, 480 V AC, 800 A, 100 kA Interrupt, 3 Poles, Electronic Trip
- MFR:
- Schneider Electric
- MFR #:
- PLA34080U33A
- Item #:
- 1578110
PLA34080U33A PowerPact Molded Case Circuit Breaker, 480 V AC, 800 A, 100 kA Interrupt, 3 Poles, Electronic Trip
- MFR #:
- PLA34080U33A
- Item #:
- 1578110
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
PowerPacTP-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Standard with a 5.0 trip unit and an LSI function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT P, 800A, 3 pole, circuit breaker has an interrupting rating of 100kA at 480VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Manuals and Documentation
| Catalog Number | PLA34080U33A |
| Manufacturer | Schneider Electric |
| Brand | Square D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | United States |
| Made in USA | Yes |
| Connection | I-Line connection, line;lugs, load; 3 x AWG 3/0...500 kcmil aluminium/copper |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=433633&lang=en-us |
| GTIN | 03606486286043 |
| Depth | 8.05 IN |
