VM18PTOQ Virtu 4-Wire Adjustable Cylindrical Ultrasonic Sensor, Ultrasonic, PNP Output, 1NO-1NC Contact, 10 to 28/12 to 24 V DC
- MFR:
- Telemecanique Sensors
- MFR #:
- VM18PTOQ
- UPC:
- 785901685937
- Item #:
- 156599
VM18PTOQ Virtu 4-Wire Adjustable Cylindrical Ultrasonic Sensor, Ultrasonic, PNP Output, 1NO-1NC Contact, 10 to 28/12 to 24 V DC
- MFR #:
- VM18PTOQ
- UPC:
- 785901685937
- Item #:
- 156599
Availability
| Location | Available Qty |
|---|---|
| Available | 2 ea |
This product is part of the Hyde Park range, an offer of ultrasonic sensors. This ultrasonic sensor in a cylindrical M18 design and adjustable sensing type window. It supports 508mm nominal sensing distance and 1 NO or NC programmable PNP discrete output. It is an ultrasonic sensor with a rated supply voltage of 12V to 24V DC with overload, short circuit protection and current consumption of 40mA. It is furnished with 4-pin M12 male connector for electrical connection. It is an IP67 and NEMA 4X rated product. The enclosure is made of PBT with glass epoxy front. Its dimensions are 77.62mm (length) x 18mm (width) x 18mm (height). It weighs 0.033kg. It is suitable for packaging, automotive, food and beverage processing applications. This product is certified by CE and UL. The Hyde Park ultrasonic sensors operate in diffuse, reflex and thru beam modes. This range of sensors even includes long distance detection models. Hyde Park ultrasonic sensors perform contactless, reliable and high performance detection regardless of the target's shape, texture, color or transparency.
Manuals and Documentation
| Catalog Number | VM18PTOQ |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | France |
| Made in USA | No |
| Application | - |
| Connector | Male connector M12 4 pins |
| Enclosure | PBT |
| Material | Plastic |
| Sensing Range | 2.00�20.00�in (50.8�508�mm) |
| Sensor | 18 MM,77.62 MM,ULTRASONIC SENSOR |
| Special Features | PLASTIC |
| Standard | 1 KV LEVEL 3 IEC 61000-4-4,10 V/M LEVEL 3 IEC 61000-4-3,30 GN IN ALL 3 AXES 11 MS IEC 60068-2-27,8 KV LEVEL 4 IEC 61000-4-2,CE,IP67,UL |
| Supply Voltage | 12...24 V DC overload and short-circuit protection |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=55982545&lang=en-us |
| UPC | 785901685937 |
| GTIN | 00785901685937 |
| Item Type | Ultrasonic sensor;Cylindrical M18 |
| Operating Temperature | -30-70 A Degrees C |
| Target Size | CYLINDER DIAMETER 2.5 MM - UP TO 200 MM SENSING DISTANCE |
| Cross Reference Products | Peperl UB50018GM75E6V15|Pepperl UB50018GM75E5V15|Schneider VM18PTOQ|Telemecan VM18PTOQ |
