XCSPA792 Preventa Corrosion-Resistant Dusttight/Watertight Turret Head Safety Interlock Switch, 300 V AC, 10 A, 2 Poles
- MFR:
- YAGEO Corporation
- MFR #:
- XCSPA792
- UPC:
- 785901619598
- Item #:
- 152840
XCSPA792 Preventa Corrosion-Resistant Dusttight/Watertight Turret Head Safety Interlock Switch, 300 V AC, 10 A, 2 Poles
- MFR #:
- XCSPA792
- UPC:
- 785901619598
- Item #:
- 152840
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$104.62
each
This key operated safety switch for guard doors, with adjustable turret head switch, has a robust red coated thermoplastic body. It's IP67 degree of protection makes it ideal for heavy duty use in harsh conditions. When wired as recommended in relevant standards, it conforms to Cat 4, performance level PL e, SIL 3.
Manuals and Documentation
| Manufacturer Part Number | XCSPA792 |
| Brand | Telemecanique |
| Manufacturer | YAGEO Corporation |
| UPC | 785901619598 |
| EAN | 3389110720631 |
| Country Of Origin | JP |
| Amperage Rating | 10 A |
| Enclosure Type | NEMA 4/4X/12/IP67 |
| Insulation Type | Double Insulated |
| Material | Plastic |
| Series | XCSPA |
| Type | Corrosion-Resistant Dusttight/Watertight Turret Head |
| Voltage Rating | 300 V AC |
| Size | 3.7 in H x 1.18 in W x 1.18 in D |
| Alternative Part Number | 10866150 |
| Manufacturer Item Status | Active |
| Country | USA/Canada |
| Warranty | 18 months |
| Standards Approvals | RoHS Compliant | Green Premium | REACH Compliant | UL File No. E164353 | UL CCN NKCR | CSA File No. LR4408794 | CSA Class 3211 03 | CE Certified | CCC Certified | CSA C22.2 No. 14 | EN 1088/ISO 14119 | EN/IEC 60204-1 | EN/IEC 60947-5-1 | EN/ISO 12100 | UL 508 | EN/ISO 13849-1 | EN/IEC 61508 | EN/IEC 60947-1 | ECCN: EAR99 | PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov |
| Application | Packaging, Handling, Robotics, Machine Tools, Presses, Automotive Sector, Safety Detection and Indoor/Outdoor Applications |
| Action | Slow Break/Simultaneous |
| Actuator Type | Key |
| Connection Type | M16 x 1.5 Cable Gland/Screw Clamp |
| Contact Configuration | 2NC |
| Environmental Conditions | -40 to 158 deg F Storage Temperature |
| Number Of Poles | 2 |
| Operating Cycles | 1000000 Cycles |
| Operating Temperature | -25 to 70 deg C |
