USB8200A5GY Duplex Grounding Tamper-Resistant USB Charger Receptacle With Green LED and Pilot Pin, 480 V AC, 60 A, 1/2 hp, 12200 W, 3 Phase, 2 Poles, 3 Wires, Gray
- MFR:
- Hubbell Wiring Device-Kellems
- MFR #:
- USB8200A5GY
- UPC:
- 883778307058
- Item #:
- 1504259
USB8200A5GY Duplex Grounding Tamper-Resistant USB Charger Receptacle With Green LED and Pilot Pin, 480 V AC, 60 A, 1/2 hp, 12200 W, 3 Phase, 2 Poles, 3 Wires, Gray
- MFR #:
- USB8200A5GY
- UPC:
- 883778307058
- Item #:
- 1504259
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
USB Charger Receptacles and Outlets - More Ways to Charge Faster with Hubbells line of USB Chargers, available in Type-C, Combination Type A&C or the legacy Type A, all with a USB high power output of 5 Amp 5 Volt DC. Hubbells USB Charger Duplex Receptacle provides both USB and electrical power in a standard single gang opening. Designed to provide maximum charging for portable electronics, the USB ports are capable of charging two tablets simultaneously. The 4 Port and 2 Port Charger Outlet feature a USB port door, which when open enables power. When closed, all power is switched OFF. This eliminates all current flow for a zero no-load draw. Buildings looking to provide 100% green efficiency in power delivery will maximize LEED and energy efficient design.
Manuals and Documentation
| Catalog Number | USB8200A5GY |
| Manufacturer | Hubbell Wiring Device-Kellems |
| Brand | Hubbell Wiring Device - Kellems |
| Country of Origin | China |
| Made in USA | No |
| Amperage Rating | 60 |
| Application | Industrial/Watertight |
| Color | Gray |
| Material | Composite |
| NEMA Rating | 5 |
| Number of Poles | 2 |
| Number of Wires | 3-Wire |
| Special Features | Switched with Pilot Pin |
| Standard | ICE 309, UL/CSA |
| UPC | 883778307058 |
| GTIN | 00883778307058 |
| Item Type | Two Type A Port |
| Voltage Rating | 480V AC |
| Wattage | 12200 |
| Wire Size | #8 To #2 AWG |
