Telemecanique

ZCKLD31 OsiSense XC Fixed Limit Switch Body, 2NO-1NC Contact, For Use With XCKL, ZCKL and ZCKM Series Standard Format Compact Limit Switch, 1.5 A at 240 V AC/0.1 A at 250 V AC/5 A at 240 V AC Contact, IP66 Enclosure

MFR:
Telemecanique Sensors
MFR #:
ZCKLD31
Item #:
1499775

Availability

Location Available Qty
Available Available to Order
$516.78 each

limit switch body ZCKL - 1NC+2NO - snap action - Cable gland include

Manuals and Documentation
Catalog Number ZCKLD31
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin Indonesia
Made in USA No
Action Snap action
Amperage Rating 6
Application XCKL
Connection Screw-clamp terminals 1 x 0.34...2 x 0.75 mm²
Contact Configuration 1 NC + 2 NO
Enclosure IP66
Number of Poles 3
Operating Cycles 5000000 CYCLES, DC-13 120 V, 4 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 24 V, 10 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 48 V, 7 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C
Special Features FIXED
Standard IK05,IP66
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=879844&lang=en-us
GTIN 03389110226492
Item Type Limit switch body
Size 1.18
Environmental Conditions STANDARD ENVIRONMENT
Operating Temperature -25-70 A Degrees C STANDARD ENVIRONMENT
Voltage Rating 1.5 A 240 V, AC-15, B300 EN/IEC 60947-5-1 APPENDIX A-0.1 A 250 V, DC-13, R300 EN/IEC 60947-5-1 APPENDIX A
