EDB34070SA Type EDB Miniature Circuit Breaker, 480Y/277 V AC, 70 A, 18 kA at 480Y/277 VAC, 25 kA at 120/240 VAC Interrupt, 3 Poles, Thermal Magnetic Trip
- MFR:
- Schneider Electric
- MFR #:
- EDB34070SA
- UPC:
- 785901112846
- Item #:
- 1491216
EDB34070SA Type EDB Miniature Circuit Breaker, 480Y/277 V AC, 70 A, 18 kA at 480Y/277 VAC, 25 kA at 120/240 VAC Interrupt, 3 Poles, Thermal Magnetic Trip
- MFR #:
- EDB34070SA
- UPC:
- 785901112846
- Item #:
- 1491216
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 70A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes a shunt trip. This breaker was calibrated for 40 degrees C. HACR rated.
Manuals and Documentation
| Catalog Number | EDB34070SA |
| Manufacturer | Schneider Electric |
| Brand | SQUARE D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | United States |
| Made in USA | Yes |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=397053&lang=en-us |
| UPC | 785901112846 |
| GTIN | 00785901112846 |
| Depth | 4.05 IN |
