Bussmann

GDA-1.6A Small Dimension Fast Acting Fuse, 1.6 A, 250 V AC/32 V DC, 1500 A Interrupt, Cylindrical Body

MFR:
Eaton
MFR #:
GDA-1.6A
UPC:
051712431316
Item #:
147578

Availability

Location Available Qty
Available Available to Order
$10.84 each

Fast-acting, high breaking capacity 5 mm x 20 mm ferrule fuse designed to IEC 60127-2 for overcurrent protection of electronic circuits.  Install into a Bussmann Series fuse holder, block or fuse clip. Also available axial leads for thru-hole installation. Eaton’s GSA fast-acting, high breaking capacity 5mm x 20mm ferrule fuses are designed to IEC 60127-2 for overcurrent protection of electronic circuits. Order in cartridge fuse format and install into a Bussmann Series fuse holder, block, or fuse clip, or purchase with available axial leads for thru-hole installation.

Manuals and Documentation

Features

  • Fast acting for maximum protection
  • High break capacity for use in higher fault energy electronic circuitry
  • Nickel plated brass end caps
  • 60 min minimum at 1.5 In, 30 min maximum at 2.1 In, 10 ms minimum and 3 s maximum at 2.75 In, 3 ms minimum and 300 ms maximum at 4 In, 20 ms maximum at 10 In response time
  • 1500 A at 250 VAC interrupt rating
Manufacturer Part Number GDA-1.6A
Brand Bussmann
Manufacturer Eaton
UPC 051712431316
Country Of Origin CN
Amperage Rating 1.6 A
Material Ceramic
Mounting Type Clip/Holder
Series GDA
Type Small Dimension
Voltage Rating 250 V AC/32 V DC
Alternative Part Number 7614358
Manufacturer Item Status Active
Country USA
Standards Approvals UL Guide JDYX2, File No. E19180 Recognized | CSA File No. 53787 | SEMKO File No. 413779, File No. 512433 | IMQ File No. EB405 | CCC File No. 2005010207155691 | IEC 60127-2
Application Electronic Circuits
Body Size 5.2 mm Dia x 20 mm H
Body Type Cylindrical
Element Single
Frequency Rating 50 Hz
Indicating Non Indicating Non-Indicating
Interrupt Rating 1500 A
Rejection Non Rejection Non-Rejection
Response Time 60 min, 30 min, 10 ms, 3 s, 3 ms, 300 ms, 20 ms
Terminal Type Ferrule
