CDFTK Qmark Trim Ring
- MFR:
- Marley Engineered Products
- MFR #:
- CDFTK
- UPC:
- 685360015040
- Item #:
- 143490
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
CDFSE “surface enclosures” are designed to mount flat on the ceiling and extend only 6 in. into the room CDFRE “recessed enclosures” have no protrusions outside recess box, allowing the heater to recess only 7 in. into ceiling space. Mounts in T-Bar or permanent ceiling with trim ring 208V and 240V heaters can be field-converted from single- to three-phase operation. 5,000-watt heater can be field-converted to 3,800 or 2,500 watts and 4,000-watt heater to 3,000 or 2,000 watts BMS-compatible with use of relays Three adjustable airflow patterns from 14 ft. ceilings: wide, narrow or asymmetrical patterns Automatic fan delay eliminates cold drafts on start-up and discharges residual heat from the heater body during shut down Automatic thermal cutout: shuts off the heater in the event of over-heating and reactivates heater when temperature returns to normal Easy installation: Thumb pins align and temporarily
Manuals and Documentation
Features
- Two Enclosures Available Order a surface or recessed enclosure, depending on your ceiling type and available install space
- Surface mounting extends only 6 in into the room, while the recessed enclosure requires only 7 in of internal clearance
- Adjustable Airflow Choose a narrow pattern to focus heat on one particular area, or a wide pattern to blanket more area
- Asymmetrical heating patterns focus output while still providing generous coverage
- BMS Compatibility Optional relays allow you to connect this ceiling heater to your central building management system, so you can control temperatures from one location
- Fan Delay The heater's fan waits until the desired temperature is achieved before blowing air into the room, and discharges all residual heat before shutting off
| Manufacturer Part Number | CDFTK |
| Brand | QMARK® |
| Manufacturer | Marley Engineered Products |
| UPC | 685360015040 |
| Country Of Origin | US |
| Suitable For Use With | CDF Series Commercial Downflow Ceiling Heater |
| Alternative Part Number | 20660947 |
| Manufacturer Item Status | Active |
| Country | USA |
| Accessory Type | Trim Ring |
| Domestic Import | Domestic |
