S200150 Sealing Hub; 2 Inch x 1-1/2 Inch, Male x Female, Malleable Iron
- MFR:
- Appleton Electric
- MFR #:
- ES200150
- UPC:
- 781381703246
- Item #:
- 143049
S200150 Sealing Hub; 2 Inch x 1-1/2 Inch, Male x Female, Malleable Iron
- MFR #:
- ES200150
- UPC:
- 781381703246
- Item #:
- 143049
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$115.89
each
UNILETS Sealing Hub, Size: 1-1/2 X 2 IN, Material: Malleable Iron, Finish: Triple-Coat (Zinc Electroplate, Chromate And Epoxy Powder Coat), Connection: Tapered MNPT X Tapered FNPT, Cubic Capacity: 4.69 CU-IN, Length: 3.13 IN, Height: 2.8
Manuals and Documentation
Features
- Dimension: 2.810 Inch Overall Dia x 3.130 Inch Height
- Accurately tapped, tapered threads for tight, rigid joints and ground continuity
- Allows up to 25% conduit fill in compliance with the national electrical code
- UL listed for use with Kwiko® A Sealing Compound
| Catalog Number | ES200150 |
| Manufacturer | Appleton Electric |
| Brand | Appleton |
| Country of Origin | Mexico |
| Made in USA | No |
| Application | For Use With Threaded Rigid Metal Conduit and IMC |
| Connection | Tapered MNPT X Tapered FNPT |
| Cubic Capacity | 4.69 CU IN |
| Finish | Triple-Coat (Zinc Electroplate, Chromate And Epoxy Powder Coat) |
| Material | Malleable Iron |
| Special Features | Explosionproof, dust-ignitionproof; Smooth, rounded integral bushing in each hub protects conductor insulation; Accurately tapped, tapered threads for tight, rigid joints and ground continuity; Allows up to 25 PCT conduit fill in compliance with the National Electrical Code; Can be used as a male thread enlarger or conduit hub in an ordinary location; UL listed for use with Kwiko A sealing compound, also listed with certain competitors sealing cement, contact factory for details; Kwiko A cement required: 1 OZ/GM; Used to seal vertical conduit risers at switch gear and motor control centers, sheet metal structures or cast boxes and enclosures |
| Standard | UL 886 (1203), UL File Number E10444, CSA C22.2 No. 30, CSA 065181, UL Listed For Class I, Groups B, C, D; Class II, Groups E, F, G; And Class III |
| RoHS Indicator | No |
| UPC | 781381703246 |
| GTIN | 00781381703246 |
| Item Type | Sealing Hub |
| Length | 10.5000 |
| Length UOM | Inch |
| Width | 7.2000 |
| Width UOM | Inch |
| Height | 1.0200 |
| Height UOM | Inch |
| Weight | 1.560 |
| Weight UOM | Pounds |
| Size | 1-1/2 X 2 |
