Safety switch, Telemecanique Safety switches XCS, metal XCSLF, 4 NC, slow break, 3 entries tapped 1/2" NPT, 120 V
- MFR:
- Telemecanique Sensors
- MFR #:
- XCSLF2727333
- UPC:
- 785901976813
- Item #:
- 140108
Safety switch, Telemecanique Safety switches XCS, metal XCSLF, 4 NC, slow break, 3 entries tapped 1/2" NPT, 120 V
- MFR #:
- XCSLF2727333
- UPC:
- 785901976813
- Item #:
- 140108
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$872.91
each
metal safety switch XCSLF - 4 NC - slow break - 3 entries tapped 1/2" NPT - 120V
Manuals and Documentation
| Catalog Number | XCSLF2727333 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Indonesia |
| Made in USA | No |
| Action | Slow-break, simultaneous |
| Actuator | KEY OPERATED TURRET HEAD |
| Amperage Rating | 4 |
| Application | KEY OPERATED TURRET HEAD |
| Color | RED |
| Connection | Spring terminal 1 x 1.5 mm² flexible or solid cable;spring terminal 2 x 0.5 mm² flexible cables with 13 mm bared ends |
| Contact Configuration | 2 NC |
| Enclosure | IP66/67 |
| Number of Poles | 2 |
| Operating Cycles | 10 CYC/MN FOR MAXIMUM DURABILITY |
| Special Features | for actuator withdrawn 1 LED (orange); for actuator inserted and locked 1 LED (green);Locking on de-energisation and unlocking on energisation of solenoid |
| Standard | 10 GN 11 MS IEC 60068-2-27,5 GN 10-500 HZ)IEC 60068-2-6,CSA-UL-TÃŒV,EN/IEC 62061-CSA C22.2 NO 14-EN/ISO 13849-1-EN 1088/ISO 14119-EN/IEC 60204-1-EN/IEC 60947-5-1-UL 508,IP66 EN/IEC 60529 AND EN/IEC 60947-5-1-IP67,CLASS I EN/IEC 61140 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=150022348&lang=en-us |
| UPC | 785901976813 |
| GTIN | 03606489413293 |
| Item Type | Safety switch |
| Size | 2.01 |
| Operating Temperature | -25-60 A Degrees C |
| Voltage Rating | 120 V - 15...10 % |
