EATON

XTPB010BC1 XT Series B-Frame Motor Protector, ON/OFF Action, 3 Poles, IP20 Enclosure

MFR:
Eaton
MFR #:
XTPB010BC1
Item #:
139155

Availability

Location Available Qty
Available Available to Order
$326.00 each

Eaton’s XT line brings IEC power control to a whole new level. The XT IEC series includes non-reversing and reversing contactors and starters as well as overload relays and accessories. Enclosed control options include metallic and non-metallic enclosures with circuit breakers, and North American or European fuses. Save space and engineering design time with XT IEC series overload relays.

Manuals and Documentation

Features

  • 4:1 maximum to minimum over current dial setting range
  • Selectable trip class (5, 10, 15, 20)
  • Interchangeable trip units
  • Three base units (12, 32 and 65 A)
  • Common accessories with the XTPR
Manufacturer Part Number XTPB010BC1
Brand EATON
Manufacturer Eaton
EAN 4015082784843
Country Of Origin DE
Amperage Rating 10 A
Dimensions 1.77 in W x 3.35 in D x 3.66 in H
Enclosure Type IP20
Series XT Series
Type B-Frame
Voltage Rating 690 V AC
Wattage 7.5 kW
Alternative Part Number 11232684
Manufacturer Item Status Active
Country USA
Warranty 1 year
Standards Approvals UL 508,CSA Std. C22.2
Application Motor and Power Control Equipment Applications
Action ON/OFF
Auxiliary Contact Rating 1NO 1NC
Connection Type Screw
Control Type Pushbutton
Frequency Rating 40 to 60 Hz
Full Load Current 6.3 to 10 A
Motor Power 10 hp
Number Of Poles 3
Operating Temperature -25 to 55 deg C
Overload Relay Bi-Metal
Phase 3
Reset Type Manual
Setting 16 A
