TCF3RN Non-Indicating Time Delay Cartridge Fuse, 3 A, 600 V AC/300 V DC, 100/300 kA Interrupt, Class: CF, Square Blade Body
- MFR:
- Eaton
- MFR #:
- TCF3RN
- UPC:
- 051712220361
- Item #:
- 139111
TCF3RN Non-Indicating Time Delay Cartridge Fuse, 3 A, 600 V AC/300 V DC, 100/300 kA Interrupt, Class: CF, Square Blade Body
- MFR #:
- TCF3RN
- UPC:
- 051712220361
- Item #:
- 139111
Availability
| Location | Available Qty |
|---|---|
| Available | 50 ea |
$119.87
each
The revolutionary BussmannTM series Low-PeakTM CUBEFuseTM delivers the smallest footprint compared to any Class CC, J or RK fuse solution — requiring up to 70 less space when combined with its unique fuse holder or UL 98 Listed Compact Circuit Protector switch. Freeing up space is powerful. And the CUBEFuse does just that, while packing up to a 300 kA interrupting rating and enabling higher equipment short-circuit current rating (SCCR). Available from 1 to 400 amps.
Manuals and Documentation
Features
- Finger safe
- Fuse Type: CUBEFuse™
- Dual element
| Manufacturer Part Number | TCF3RN |
| Brand | Bussmann |
| Manufacturer | Eaton |
| UPC | 051712220361 |
| Amperage Rating | 3 A |
| Color | Black |
| Material | Glass Filled Polyethersulfone |
| Mounting Type | Chassis/DIN Rail |
| Series | TCF |
| Type | Non-Indicating Time Delay |
| Voltage Rating | 600 V AC/300 V DC |
| Alternative Part Number | 10771137 |
| Manufacturer Item Status | Active |
| Country | USA |
| Standards Approvals | CE Certified | CSA Certified | UL Listed |
| Application | Commercial/Institutional Buildings/structures, Power Distribution and Control, Electrical Panel Boards, Machinery Disconnects, Industrial Control and Required Finger safe system Applications, Safety and Security Systems, Stationary Machinery and Equipment Outside Factory |
| Body Size | 0.81 in Dia x 3 in L |
| Body Type | Square Blade |
| Class | CF |
| Element | Dual |
| Frequency Rating | 50/60 Hz |
| Interrupt Rating | 100/300 kA |
| Response Time | 10 s at 500% |
| Terminal Type | Blade |
