M9L11120 Multi 9 Surge Arrester, 20 kA, 1 poles, 200 kA sccr
- MFR:
- Schneider Electric
- MFR #:
- M9L11120
- Item #:
- 1383104
M9L11120 Multi 9 Surge Arrester, 20 kA, 1 poles, 200 kA sccr
- MFR #:
- M9L11120
- Item #:
- 1383104
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
This Multi9 PRD1 product is a surge arrester. it can be installed in a variety of installations including service entrance, branch panels and control panel environments. It is connected to electrical distribution network. Its surge arrester class type is type 1. The Imax maximum discharge current is 75kA. It can be associated with a 30A and C curve tripping circuit breaker. The Uc maximum continuous operating voltage is 175VAC in common mode (L/N). The In nominal discharge current is 20kA ( L/PE). The Up maximum voltage protection level is 600V. It can be mounted on DIN rail for modular installation. Its width is 2 pitches of 9mm. The degree of protection is NEMA 1. The operating temperature is -25C to 60C. The storage temperature is -40C to 85C. This product complies with UL 1449 standard.
Manuals and Documentation
| Catalog Number | M9L11120 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Country of Origin | France |
| Made in USA | No |
| Response Time | < 25 ns |
| Standard | UL 1449:ed. 4 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=533483603&lang=en-us |
| GTIN | 03606485010199 |
