CTV02-KD0 Split Core Current Transformer, 200 A Primary, 333 mV, 50/60 Hz

MFR:
Leviton
MFR #:
CTV02-KD0
UPC:
078477675731
Item #:
1345976

Availability

Location Available Qty
Available Available to Order
$146.38 each

Leviton® 333 mV Current Transformers (CTs) support the series 4000, series 4100, series 7000 and series 7100 lines of revenue-grade meters and help meet all measurement and verification based opportunities, including smart metering and LEED rating achievement. Designed as part of a simple and effective process for accurately capturing measurements of power consumption, CTs are easy to specify and install for new construction and retrofits. The better the equipment, the better the measurement. Leviton® meters utilize highly accurate current transformers for revenue-grade performance certified to ANSI standards. Solid core CTs are standard for high quality, long term accuracy and reliability. For added safety, all Leviton® current transformers come with built-in voltage suppression devices that prevent hazardous voltages from developing on CT secondaries should they become disconnected from a meter with load current present. Leviton® CTs are UL and cUL listed devices.

Manuals and Documentation

Features

  • Split core CTs can be disassembled or split into halves eliminating the need to turn power off and open the circuit during installation
  • This time saving installation is ideal for critical loads that cannot be disconnected
  • Leviton® split core CTs are designed to close and lock to ensure a secure, fast and precise installation with no need for time consuming tie wraps and no worries about improper seating or core separation
  • Indoor type for measurement category Class IV, accessory equipment for energy meters
  • Suitable for installation on 600 V uninsulated bus duct
Manufacturer Part Number CTV02-KD0
Brand Leviton®
Manufacturer Leviton
UPC 078477675731
Country Of Origin US
Dimensions 2.87 in W x 1.11 in D x 3.24 in H
Type Split Core
Voltage Rating 333 mV
Alternative Part Number 15971435
Manufacturer Item Status Active
Country USA
Standards Approvals ANSI Specified | CE Certified | CSA C22.2 File No. 61010-1 | cULus File No. E361441 | UL 916
Application Load Profiling and Benchmarking, AMR/BAS/BMS/EMS Integration, Power Quality Analysis, Usage Aggregation, Tenant Cost Allocation, Measurement and Verification, Net Metering, Energy Conservation and Cost Reduction, Green Building Initiatives and Government Mandates
Accuracy 0.5 %
Connection Type Wire Lead
Frequency Rating 50/60 Hz
Primary Current 200 A
