Discontinued
Square D

9007MS01S0054 Fixed Miniature Potted Limit Switch, 120/240 VAC, 28 VDC, 3 A, 1CO 1 Form C SPDT Contact, 1 Pole

MFR:
Schneider Electric
MFR #:
9007MS01S0054
UPC:
785901844617
Item #:
131847

Availability

Location Available Qty
Available Available to Order

LIMIT SWITCH 240VAC 10AMP MS +OPTIONS

Manuals and Documentation
Catalog Number 9007MS01S0054
Manufacturer Schneider Electric
Brand Square D
Country of Origin Mexico
Made in USA No
Action ON END,SNAP ACTION,VERTICAL APPROACH, 1 DIRECTION
Actuator SPRING RETURN PLUNGER STAINLESS STEEL -
Amperage Rating 3
Application 9007MS/ML,MINIATURE POTTED,PLUNGER HEAD
Connection MALE CONNECTOR M12 MICRO DC TYPE 4 PINS BOTTOM
Contact Configuration NC-NO
Enclosure NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 6 NEMA TYPE 250-NEMA 6P NEMA TYPE 250
Mounting By The Body
Operating Cycles 100000 CYCLES
Special Features FIXED,METAL
Standard 10 GN 75-1200 HZ)IEC 60068-2-6,35 GN 9 MS IEC 60068-2-27,IP67 IEC 60529,LR 25490 CLASS 32 11 03-E78403,UL-CE-CSA
UPC 785901844617
GTIN 00785901844617
Item Type LIMIT SWITCH,PLUNGER HEAD
Size 0.62 IN,1.56 IN,1.75-1.75 IN
Operating Temperature -40-220 A Degrees F
Voltage Rating 3 A 28 V DC-3 A 120 V AC-3 A 240 V AC
