Eaton Bussmann Series

315FM FM Series British Standard Semi-Conductor High Speed Fuse, 315 A, 690 V AC, 200 kA Interrupt

MFR:
Eaton Bussmann
MFR #:
315FM
UPC:
051712833806
Item #:
128398

Availability

Location Available Qty
Available Available to Order
$855.78 each

Eaton's Bussmann British standard BS88 fuses can be used in multiple applications; industrial, utility, street lighting and domestic. Full range of rated current and voltage available as well as compatible fuse holders. They meet the BS88 part 1 and 2 and IEC 60269-1 and -2 standards.

Manuals and Documentation
Catalog Number 315FM
Manufacturer Eaton Bussmann
Brand Eaton Bussmann Series
Country of Origin India
Made in USA No
Amperage Rating 315
Application Ind Facilities & Factories - Facility: Safety and Security Systems|Elec Assemblies, Panels & EOEM - Panel Builders|Elec Assemblies, Panels & EOEM - Elec Assemblies/Panels/EOEMs - Aftermarket|Elec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other|Ind Facilities & Factories - Facility: Power Distribution and Control|Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs|Elec Assemblies, Panels & EOEM - Control Panels for Machines
Connection Blade end x blade end
Interrupt Rating 200 kA RMS Sym (IEC/UL), 40 kA at 450 Vdc (IEC), 50 kA at 500 Vdc (UL)
Mounting Stud
Special Features Low Arc Voltage, Excellent Cycling Capacity, Excellent DC Performance, Power Loss 55 W, Interrupt Rating 200 kA (RMS Symmetrical)
Standard IEC Rated ,UL Recognized ,Designed and tested to BS88 part 4 ,UL recognized ,CCC ,IEC 60269-4,CE Marked,RoHS Compliant
UPC 051712833806
GTIN 00051712833806
Item Type High speed british standard fuse
Weight UOM Grams
Size 113.00 mm Length X 38.10 mm Width X 41.00 mm Height
Voltage Rating 690 V (IEC), 700 V (UL)
