LC1K09103B7 LC1K Series Contactor, 24 V AC v coil, 9 to 20 A, 3NO contact, 3 poles
- MFR:
- Schneider Electric
- MFR #:
- LC1K09103B7
- Item #:
- 1218651
LC1K09103B7 LC1K Series Contactor, 24 V AC v coil, 9 to 20 A, 3NO contact, 3 poles
- MFR #:
- LC1K09103B7
- Item #:
- 1218651
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
LC1K09103B7 is a compact 3-pole TeSys K contactor from Schneider Electric for motor applications 9A AC-3 4kW@400V. It provides a 24V 50/60Hz AC coil, 1NO auxiliary contact and connections by spring terminals. LC1K09103B7 is a 3-pole TeSys K contactor from Schneider Electric for simple motor applications rated 4kW@400V. Very compact, DIN-rail compatible, it provides a 24V 50/60Hz AC coil, 1NO built-in auxiliary contact and connections by spring terminals. Available worldwide, it complies with multi-standards (IEC, UL, CSA, CCC, EAC, Marine). Very compact, 45mm wide, for DIN-rail and panel mounting. Provides 1NO built-in auxiliary contact and a control circuit compatible with 50Hz and 60Hz supplies. Model with spring terminals for fast wiring and lasting contact quality. Optimized for simple power applications. Can be added with clip-on auxiliary contact blocks with spring terminals (LA1KN.3) and clip-on suppressor modules with LED indicator (LA4K.).
Manuals and Documentation
| Catalog Number | LC1K09103B7 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Indonesia |
| Made in USA | No |
| Application | Motor control;resistive load |
| Coil Voltage | 24 V AC 50/60 Hz |
| Contact Configuration | 1 NO |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=622802&lang=en-us |
| GTIN | 03389110242072 |
| Item Type | Contactor;LC1K |
