Mini circuit breaker, QOU, 10A, 2 pole, 120/240 VAC, 10kA, bulk pack

MFR:
Schneider Electric
MFR #:
QOU210B
UPC:
785901142591
Item #:
1207703

Availability

Location Available Qty
Available 20 ea

QOU unit mount miniature circuit breakers (cable-in/cable-out) are ideal for OEM applications. QOU breakers are one, two or three pole thermal magnetic circuit breakers which provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. These QOU miniature circuit breakers can be DIN rail mounted, surface mounted or flush mounted using mounting feet. This two pole QOU miniature circuit breaker is rated as 10A, 120/240VAC. This unit provides 10 kA breaking capacity. A full line of accessories are available for these circuit breakers. The slotted box lugs will accept one 14 AWG to 2 AWG copper or aluminum wire. QOU circuit breakers are UL Listed and CSA Certified. This is a bulk pack.

Manuals and Documentation
Catalog Number QOU210B
Manufacturer Schneider Electric
Brand Square D
Warranty Description Contractual Warranty:18 months
Country of Origin Mexico
Made in USA No
Application HACR rated
Connection Slotted box lugs, line side;slotted box lugs, load side;AWG 14...AWG 2 aluminium/copper
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=402161&lang=en-us
UPC 785901142591
GTIN 00785901142591
Item Type Miniature circuit-breaker
Width 1.500000000000000
Width UOM Inch
Height 4.050000000000000
Height UOM Inch
Depth 2.95 IN
Voltage Rating 120/240 V AC;120 V AC;48 V DC
