Discontinued
Mechanical alternator, Pumptrol, mech closed tank, NEMA 1, screw in bushing, 4 NC DPST DB contacts
- MFR:
- Schneider Electric
- MFR #:
- 9038CG31N5
- UPC:
- 785901962564
- Item #:
- 1198859
Discontinued
Mechanical alternator, Pumptrol, mech closed tank, NEMA 1, screw in bushing, 4 NC DPST DB contacts
- MFR #:
- 9038CG31N5
- UPC:
- 785901962564
- Item #:
- 1198859
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
mech alternator -closed tank - NEMA 1 - screw-in bushing - 4 NC DPST-DB contacts
Manuals and Documentation
| Catalog Number | 9038CG31N5 |
| Manufacturer | Schneider Electric |
| Brand | Square D |
| Warranty Description | Contractual Warranty: 18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| Action | Contacts close on liquid rise |
| Application | Mechanically alternating the operation of two pumps or motors;Power circuit with control duty alarm;Closed tank with bushing;For closed tank |
| Connection | Screw-clamp terminals 10 AWG;8 terminals |
| Enclosure | NEMA 1 |
| Mounting | Screw |
| Number of Poles | 2 |
| Special Features | Set of 1;Addition of a third, high-water alarm circuit (SPST-NO-DB) |
| Standard | NEMA 1 UL 50,UL 508-CE,UL LISTED FILE E12158-CSA FILE LR25490 |
| UPC | 785901962564 |
| GTIN | 00785901962564 |
| Item Type | Mechanical alternator |
| Temperature Rating | -22-220 A Degrees F |
| Voltage Rating | 575VAC |
