XTD1A2A2 AC Rated ON/OFF Toggle Switch, 125/277 VAC, 28 VDC, 10/15/20 A, 3/4 hp, SPST
- MFR:
- Eaton
- MFR #:
- XTD1A2A2
- UPC:
- 786685227153
- Item #:
- 1153102
XTD1A2A2 AC Rated ON/OFF Toggle Switch, 125/277 VAC, 28 VDC, 10/15/20 A, 3/4 hp, SPST
- MFR #:
- XTD1A2A2
- UPC:
- 786685227153
- Item #:
- 1153102
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
Eaton AC rated XT series toggles offer a standard high rating for both single and double pole applications. The XT series toggle line offers a wide range of switching circuits, functions and accessories. Ratings for single and double pole include 20 A at 125 VAC and 10 A at 277 VAC to handle more severe inductive, motor and lamp loads. In addition, XT series toggles have a high standard horsepower rating of 1-1/2 hp from 125 to 250 VAC for double pole applications. The easy to install toggles also have an industry standard 0.48 in Dia mounting hole. For added convenience and delivery support, select industry standard switch circuit part numbers are available from stock. With so many features, XT series can be used in a variety of applications.
Manuals and Documentation
Features
- 20 A at 125 VAC, 10 A at 277 VAC, 15 A at 28 VDC
- 3/4 hp at 125 to 250 VAC
| Manufacturer Part Number | XTD1A2A2 |
| Brand | EATON |
| Manufacturer | Eaton |
| UPC | 786685227153 |
| Country Of Origin | CN |
| Amperage Rating | 10/15/20 A |
| Dimensions | 1.125 in L x 0.629 in W x 1.794 in H |
| Enclosure | IP40 |
| Material | Thermoset |
| Series | X Series |
| Type | AC Rated ON/OFF |
| Voltage Rating | 125 to 277 V AC/28 V DC |
| Alternative Part Number | 11505664 |
| Manufacturer Item Status | Active |
| Country | USA |
| Warranty | 2 Years |
| Standards Approvals | UL Listed file E2702,RoHS Compliant |
| Application | Automation and Logic Control Equipment, Commercial and Industrial Equipment, Household Appliances, Industrial Machinery and Automation, Medical Equipment, Military Communications and Surveillance, Rail Systems, Signaling and Communications, Test and Lab Equipment, Telecommunications, Cable and Broadcasting Applications |
| Includes | Zinc Nickel Plated Knurl Nut and Hex Nut |
| Actuator | Toggle |
| Closed Contact Resistance | 50 Ohm |
| Contact Configuration | SPST |
| Environmental Conditions | 32 to 149 deg F Operating Temperature |
| Mounting | Threaded |
| Number Of Poles | 1 |
| Power Rating | 3/4 |
| Terminal Type | Screw |
