SQUARE D

JJP36200 PowerPact Type JJP Molded Case Circuit Breaker, 600 VAC, 250 VDC, 200 A, 20/25/65/100 kA Interrupt, 3 Poles, Thermal Magnetic Trip

MFR:
Schneider Electric
MFR #:
JJP36200
UPC:
785901660941
Item #:
1143827

Availability

Location Available Qty
Available Available to Order
$5,884.67 each

PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units. This PowerPacT J-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT J-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT J circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This unit has terminal nuts on the line side and lugs on the load side. This PowerPacT J, 200A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT J circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.

Manuals and Documentation
Catalog Number JJP36200
Manufacturer Schneider Electric
Brand SQUARE D
Warranty Description Contractual Warranty:18 months
Country of Origin United States
Made in USA Yes
Connection Terminal nut, line;lugs, load; AWG 3/0...350 kcmil aluminium/copper terminals
Control Toggle
Number of Poles 3
Special Features Modbus
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=426157&lang=en-us
UPC 785901660941
GTIN 00785901660941
Item Type Circuit breaker
Trip Type Thermal-magnetic
Cross Reference Products Schneider JJP36200|Siemens HFXD63B200|SquareD JJP36200
