SQUARE D

MJA36800YP PowerPact MasterPact Molded Case Circuit Breaker, 600 V AC, 800 A, 25 kA Interrupt, 3 Poles, Electronic Trip

MFR:
Schneider Electric
MFR #:
MJA36800YP
Item #:
1096355

Availability

Location Available Qty
Available Available to Order
$13,814.67 each

PowerPacTM-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version. This circuit breaker has an electronic trip unit, ET 1.0. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT M circuit breakers are available in 2 and 3-pole unit mount or I-Line construction. This unit has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT M, 800A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. This unit includes a factory installed handle padlocking device, off or on. PowerPacT M circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.

Manuals and Documentation
Catalog Number MJA36800YP
Manufacturer Schneider Electric
Brand SQUARE D
Warranty Description Contractual Warranty:18 months
Country of Origin United States
Made in USA Yes
Color Black
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=431085&lang=en-us
GTIN 03606486284797
Width 8.27
Width UOM Inch
Height 12.86
Height UOM Inch
Depth 8.05 IN
